TK-WS30
Aircraft Wastewater Truck
The TK-WS30 is a lavatory service truck with vacuum waste removal, clean-water supply, stainless-steel tanks, and a 380–2900 mm lifting platform for efficient aircraft servicing.
Vacuum extraction system
Standard lifting platform
Independent reinforced subframe
High-quality stainless-steel construction
Specifications
Water Supply Pressure
0.25 – 0.35 MPa
Wastewater Capacity
2000 L
Suction Vacuum
0.2 bar
Fresh Water Capacity
1000 L
Dimensions (L × W × H)
6880 × 2100 × 2150 mm
Wheelbase
3360 mm
Lift Height (Optional)
380 – 2900 mm
Curb Weight
3700 kg
Turning Diameter
15000 mm
Aircraft Range
A318/319/320/321, A300/310, A330/340, A350, B737, B747, B757, B767, B777, B787,
ERJ145/E170/E190, F50/F100, CRJ-900, MD-80/90/11, DC-10, C919
